Death Star Clock - REMIX

Mix and match of different parts from the following links to create a new clock combo. Up to four colours for each plate

•  Print larger pieces at 0.20mm or 0.22mm layer height
• Smaller pieces at 0.14mm to 0.16mm
• Printed using hardened steel 0.4mm nozzle on Kobra S1 combo
• Organic tree supports with a Z-top distance 0.275mm just come off like butter
• Slow first 2 or 3 layers for dainty pieces to 30mms for good adherence
• Ironing - rectilinear 10%

If you are not keen on the numbered housing holding the clock face further from the wall, make sure you cut away the 4 small lifters on the inside of the ring for the numbers.

Changes to files include

• Cut down and added hole for the second hand, scaled to fit tie fighter or x-wing for the end of second hand.
• Coloured each piece as accurately as possible to align with a 4 colour AMS/ACE pro
• Scaled optional surrounds to fit and display either Roman numerals or Numbers. (note: scale numerical pieces 1mm DOWN for tight fit ring, leave as-is for looser fit as per first picture) Dont forget to trim small bolsters with side cutters on inside wall.

The holes at the attachment points of the hands need to be slightly widened. This was intentional so that the clock arms fit snugly with variations in mechanisms and printers :)
